电缆桥架生产的表面处理有哪些区别

电缆桥架在我们的生活中每个地方都会用得到,它们保护着电缆不被外界破坏,而且电缆桥架的类型也有着很多的不同。据了解,不同的电缆桥架表面的处理方式是不一样的,不同的环境要用到不同的电缆桥架,下面我们看看电缆桥架表面处理的区别。
Cable trays can be used everywhere in our life. They protect cables from being damaged by the outside world, and there are many different types of cable trays. It is understood that the surface treatment methods of different cable trays are different. Different cable trays are used in different environments. Let's look at the differences in surface treatment of cable trays.
热镀锌电缆桥架:成品酸洗-水洗-加助镀液-烘干-挂镀-冷却-药化-清洗-打磨热镀锌完工。是一种有效的金属防腐方式,主要用在每个行业的金属结构设施上。是将除锈后的钢件浸入500℃左右融化的锌液中,使钢构件表面附着锌层,从而起到防腐的目的
Hot dip galvanized cable tray: finished product Pickling - water washing - adding auxiliary plating solution - drying - hanging plating - cooling - medicating - Cleaning - polishing hot dip galvanizing is completed. It is an effective metal corrosion prevention method, mainly used in metal structure facilities in every industry. It is to immerse the derusted steel parts into the molten zinc at about 500 ℃, so that the zinc layer is attached to the surface of the steel members, so as to achieve the purpose of corrosion prevention
在这里告诉大家热喷锌涂层表面由分布均匀的锌粒组成,其粗糙程度对喷漆具有很好的附着力,使漆面不易脱落。同时又不会造成漆面不光滑而影响美观。 热喷锌不会对工件造成变型。 因为热喷锌只在工作表面产生瞬间高温,不会至任何工件发生形变。
Here we tell you that the surface of the hot sprayed zinc coating is composed of evenly distributed zinc particles, and its roughness has good adhesion to the paint, so that the paint surface is not easy to fall off. At the same time, it will not cause the paint surface to be not smooth and affect the appearance. Hot spraying zinc will not cause deformation to the workpiece. Because the hot spraying zinc only produces instantaneous high temperature on the working surface, it will not cause deformation to any workpiece.
喷塑电缆桥架:是将塑料粉末喷涂在电缆桥架上的一种表面处理方法。不需稀料,施工对环境无污染,对人体无毒害;涂层外观质量优异,附着力及机械强度强;喷涂施工固化时间短;涂层耐腐耐磨能力高出很多;不需底漆;施工简便,对工人技术要求低;成本低于喷漆工艺;有些施工场合已经明确提出使用静电喷塑工艺处理;静电喷粉喷涂过程中不会出现喷漆工艺中常见的流淌现象。
Spray plastic cable tray: it is a surface treatment method of spraying plastic powder on the cable tray. No thinner is required, the construction will not pollute the environment and will not harm the human body; The coating has excellent appearance quality, strong adhesion and mechanical strength; The curing time of spraying construction is short; The corrosion and wear resistance of the coating is much higher; No primer is required; Simple construction and low technical requirements for workers; The cost is lower than the painting process; Some construction sites have clearly proposed the use of electrostatic spraying process; There will be no common flow phenomenon in the process of electrostatic powder spraying.
冷镀锌电缆桥架:是利用电解设备将电缆桥架经过除油酸洗、后放入成分为盐的溶液中,并连接电解设备的负极,在电缆桥架的对面放置锌版,连接在电解设备的正极接通电源,利用电流从正极向负极的定向移动就会在电缆桥架上沉积一层锌,冷镀电缆桥架是先加工后镀锌。
Cold galvanized cable tray: it is to use the electrolytic equipment to wash the cable tray with oleic acid and then put it into the solution containing salt, connect the negative electrode of the electrolytic equipment, place a zinc plate on the opposite side of the cable tray, connect the positive electrode of the electrolytic equipment to the power supply, and use the current to move from the positive electrode to the negative electrode to deposit a layer of zinc on the cable tray. The cold galvanized cable tray is processed first and then galvanized.
防火电缆桥架:防火桥架外观与喷塑桥架比较相似,不过性能完全不同,防火桥架主要性能是防火,有一定的防火等级,常用于有防火要求的场所,表面粗糙,表面摸起来会有粗糙斜斜的感觉,当遇到火灾后不会燃烧,并且可以阻隔火势继续蔓延下去,起到一定的防火作用,防火涂层可以针对施工环境设计去选择桥架的颜色。
Fire resistant cable tray: the appearance of fire-resistant cable tray is similar to that of spray plastic tray, but the performance is completely different. The main performance of fire-resistant cable tray is fire protection. It has a certain fire rating. It is often used in places with fire protection requirements. The surface is rough and the surface feels rough and oblique. It will not burn in case of fire, and can prevent the fire from continuing to spread, playing a certain fire protection role, The fireproof coating can be designed to select the color of the bridge according to the construction environment.
以上就是为大家介绍的有关电缆桥架的详细的介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度,为您提供服务http://www.sdhangfeng.com
The above is the detailed introduction of the cable tray for you. I hope it will help you. If you have any questions, please contact us. We will provide you with services with a professional attitude http://www.sdhangfeng.com
