在电气布线系统中，电缆桥架是一种用于支撑、保护和管理电缆的结构化装置，广泛应用于各类建筑和工业场所。它通过标准化的设计和灵活的组合方式，为电缆提供了有序的敷设通道，既保障了电缆的正常运行，又便于后期的维护和检修，是现代电气安装工程中不可或缺的重要组成部分。

　　In electrical wiring systems, cable trays are structured devices used to support, protect, and manage cables, widely used in various buildings and industrial sites. It provides a safe and orderly laying channel for cables through standardized design and flexible combination methods, ensuring the normal operation of cables and facilitating later maintenance and repair. It is an indispensable and important component of modern electrical installation engineering.

　　从定义来看，电缆桥架是由支架、托臂和安装附件等组成的刚性结构系统，主要用于承载电力电缆、控制电缆、通信电缆等各类线缆。与传统的穿管敷设方式不同，电缆桥架采用开放式或半开放式结构，能让电缆有序排列并暴露在外（部分类型带有盖板），不仅便于散热，还能直观地观察电缆的运行状态，及时发现破损、老化等问题。其设计遵循标准化原则，不同规格、型号的桥架可通过连接件灵活组合，适应不同的敷设路径和空间要求，满足多样化的布线需求。

　　From a definition perspective, cable tray is a rigid structural system composed of brackets, support arms, and installation accessories, mainly used to carry various types of cables such as power cables, control cables, communication cables, etc. Unlike traditional conduit laying methods, cable trays adopt an open or semi open structure, which allows cables to be arranged in an orderly manner and exposed to the outside (some types have cover plates). This not only facilitates heat dissipation, but also allows for intuitive observation of cable operation status, timely detection of damage, aging, and other issues. Its design follows the principle of standardization, and different specifications and models of cable trays can be flexibly combined through connectors to adapt to different laying paths and space requirements, meeting diverse wiring needs.

　　电缆桥架的基本结构包括主体框架和辅助配件。主体框架通常由托盘、梯架或槽式壳体构成，是承载电缆的核心部分：托盘式桥架由底部带有散热孔的钢板或铝合金板制成，结构轻便，适合敷设截面较小的电缆；梯架式桥架由两侧的立板和中间的横档组成，形似梯子，透气性好，承载能力强，多用于大直径电力电缆的敷设；槽式桥架则是封闭或半封闭的壳体结构，能为电缆提供更好的防护，适合在灰尘多、潮湿或有腐蚀性的环境中使用。辅助配件包括支架、托臂、连接件、盖板等，支架和托臂用于将桥架固定在墙体、天花板或地面上，确保桥架安装牢固；连接件用于桥架之间的拼接，保证敷设路径的连续性；盖板则可根据需要加装，起到防尘、防水、防外物撞击的作用。

　　The basic structure of cable tray includes the main frame and auxiliary accessories. The main frame is usually composed of trays, ladders, or trough type shells, and is the core part that carries cables: tray type cable trays are made of steel plates or aluminum alloy plates with heat dissipation holes at the bottom, which are lightweight in structure and suitable for laying cables with smaller cross-sections; The ladder style bridge is composed of two vertical plates on both sides and a crossbar in the middle, resembling a ladder, with good breathability and strong load-bearing capacity. It is commonly used for laying large-diameter power cables; Slot type cable trays are enclosed or semi enclosed shell structures that provide better protection for cables and are suitable for use in dusty, humid, or corrosive environments. Auxiliary accessories include brackets, support arms, connectors, cover plates, etc. The brackets and support arms are used to fix the bridge to the wall, ceiling, or floor, ensuring that the bridge is installed firmly; Connectors are used for splicing between cable trays to ensure the continuity of the laying path; The cover plate can be installed as needed to prevent dust, water, and external object impact.

　　根据材质的不同，电缆桥架可分为多种类型，以适应不同的使用环境。钢制电缆桥架是常见的类型，采用冷轧钢板加工而成，通过镀锌、喷漆等表面处理提升耐腐蚀性，具有强度高、适中的特点，适合一般工业与民用建筑。铝合金电缆桥架重量轻、耐腐蚀性强，表面经阳极氧化处理后美观耐用，多用于潮湿环境或对重量有严格限制的场所，如高层建筑、化工车间等。玻璃钢电缆桥架由玻璃纤维和树脂复合而成，具有优异的耐酸碱、抗老化性能，且不导电、不导热，适合在有强腐蚀介质的环境中使用，如电镀车间、污水处理厂等。此外，还有防火电缆桥架，其表面涂覆防火涂料或采用阻燃材料制造，能在火灾发生时延缓火势蔓延，为电缆的应急供电争取时间，适用于消防系统等重要电路的敷设。

　　According to the different materials, cable trays can be divided into various types to adapt to different usage environments. Steel cable trays are the most common type, processed from cold-rolled steel plates and improved in corrosion resistance through surface treatments such as galvanizing and painting. They have the characteristics of high strength and moderate price, and are suitable for general industrial and civil buildings. Aluminum alloy cable trays are lightweight, highly corrosion-resistant, and have a beautiful and durable surface after anodizing treatment. They are commonly used in humid environments or places with strict weight restrictions, such as high-rise buildings and chemical workshops. Glass fiber reinforced plastic cable tray is composed of glass fiber and resin. It has excellent acid and alkali resistance, anti-aging performance, and does not conduct electricity and heat. It is suitable for use in environments with strong corrosive media, such as electroplating workshops, sewage treatment plants, etc. In addition, there are fire-resistant cable trays, whose surfaces are coated with fire-resistant coatings or made of flame-retardant materials, which can delay the spread of fire in the event of a fire, buy time for emergency power supply of cables, and are suitable for laying important circuits such as fire protection systems.

　　电缆桥架的主要作用体现在保护、管理和优化电缆敷设三个方面。在保护方面，它能将电缆与外界环境中的机械损伤、化学腐蚀、灰尘水汽等隔离开来，减少电缆因外力或环境因素导致的故障，延长电缆的使用寿命。在管理方面，桥架通过分层、分区域的设计，将不同功能、不同电压等级的电缆分开敷设，避免了电缆之间的相互干扰，尤其对控制电缆和通信电缆而言，能减少信号干扰，保证传输质量。在优化敷设方面，桥架可根据建筑结构和布线需求，灵活设计成水平、垂直、转弯、爬坡等多种路径，充分利用建筑空间，使电缆敷设更加规整美观，避免了线缆杂乱无章的现象，同时为后期的扩容和改造提供了便利，只需增加桥架单元即可新增电缆。

　　The main functions of cable trays are reflected in three aspects: protection, management, and optimization of cable laying. In terms of protection, it can isolate cables from mechanical damage, chemical corrosion, dust and water vapor in the external environment, reduce cable failures caused by external forces or environmental factors, and extend the service life of cables. In terms of management, cable trays are designed with layers and zones to separate cables of different functions and voltage levels, avoiding mutual interference between cables. Especially for control cables and communication cables, it can reduce signal interference and ensure transmission quality. In terms of optimizing cable laying, cable trays can be flexibly designed into various paths such as horizontal, vertical, turning, climbing, etc. according to the building structure and wiring requirements, fully utilizing the building space to make cable laying more orderly and beautiful, avoiding the phenomenon of disorderly cables, and providing convenience for later expansion and renovation. Only by adding cable tray units can new cables be added.
