电缆桥架型式都有哪些？
1、需屏蔽电气干扰的电缆网路或有防护外部（如：有腐蚀液休，易燃粉尘等环境）影响的要求时，应选用（FB）类槽式复合型防腐屏蔽电缆桥架（带盖）。
1. When the cable network that needs to be shielded from electrical interference or is required to be protected from external influences (such as corrosive liquid, flammable dust, etc.), the (FB) type trough-type composite anti-corrosion shielded cable bridge (with cover) shall be selected.
2、强腐蚀性环境应采用（F）类复合环氧树脂防腐阻燃型电缆桥架。托臂、支架也要选用同样材料，提高桥架及附件的使用寿命，电缆桥架。在容易积灰和其它需遮盖的环境或户外场所宜加盖板。
2. Class (F) composite epoxy resin anti-corrosion flame-retardant cable tray shall be used in highly corrosive environment. The same materials shall be used for the bracket and bracket to improve the service life of the cable tray and accessories. Cover plates should be added in the environment or outdoor places that are easy to accumulate dust and need to be covered.
3、除上述情况外，可根据现场环境及技术要求选用托盘式、槽式、梯级式、玻璃防腐阻燃电缆桥架或钢质普通型桥架。在容易积灰和其它需遮盖的环境或户外场所宜加盖板。
3. In addition to the above situations, tray type, trough type, cascade type, glass anti-corrosion flame-retardant cable tray or steel common type cable tray can be selected according to the site environment and technical requirements. Cover plates should be added in the environment or outdoor places that are easy to accumulate dust and need to be covered.
4、在公共通道或户外跨越道路段，底层梯级的底部宜加垫板或在该段使用托盘。大跨距跨越公共通道时，可根据用户要求提高桥架的载荷能力或选用行架。
4. In the public passage or outdoor crossing road section, the bottom of the bottom rung should be added with a pad or pallets should be used in this section. When crossing a public passage with a large span, the load capacity of the bridge can be improved or the rack can be selected according to the user's requirements.
5、大跨距（>3m）要选用复合型桥架（FB）。
5. Composite bridge (FB) shall be selected for large span (>3m).
6、户外要选用复合环氧树指桥架（F）。
6. Composite epoxy tree-finger bridge (F) shall be selected for outdoor use.
