热镀锌电缆桥架?以冷轧钢板制成，表面工艺为热镀锌，由槽式、托盘式或梯级式的直线段、弯通、三通、四通组件以及托臂（臂式支架）、吊架等构成具有密接支撑电缆的刚性结构系统之全称。在各种保护钢基体的涂镀方法中，热镀锌是非常优良的一种。它是在锌呈液体的状态下，经过了相当复杂的物理、化学作用之后，在钢铁上不仅镀上较厚的纯锌层，而且还生成一种锌一铁合金层。这种镀法，不仅具备了电镀锌的耐腐蚀特点，而且由于具有锌铁合金层。还具有电镀锌所无法相比拟的强耐蚀性。因此这种镀法特别适用于各种强酸、碱雾气等强腐蚀环境中。热镀锌的应用随着工农业的发展也相应扩大。因此，热镀锌制品在工业（如化工设备、石油加工、海洋勘探、金属结构、电力输送、造船等），农业（如：喷灌、暧房）、建筑（如：水及煤气输送、电线套管、脚手架、房屋等）、桥梁、运输等方面，近几年已大量地被采用。由于热镀锌制品具有外表美观、耐腐蚀性能好等特点，其应用范围越来越广泛。

　　Hot dip galvanized cable trays are made of cold-rolled steel plates and have a surface process of hot-dip galvanizing. They consist of straight sections, bends, tees, and tees in trough, tray, or step styles, as well as support arms (arm brackets), hangers, and other components to form a rigid structural system that tightly supports cables. Among various coating methods for protecting steel substrates, hot-dip galvanizing is an excellent one. It is a process in which zinc is in a liquid state and undergoes complex physical and chemical reactions, resulting in the deposition of a thick layer of pure zinc on steel and the formation of a zinc iron alloy layer. This plating method not only has the corrosion resistance characteristics of electroplated zinc, but also has a zinc iron alloy layer. It also has strong corrosion resistance that cannot be compared to electroplated zinc. Therefore, this plating method is particularly suitable for various strong acid, alkali mist and other highly corrosive environments. The application of hot-dip galvanizing has also expanded with the development of industry and agriculture. Therefore, hot-dip galvanized products have been widely used in industry (such as chemical equipment, petroleum processing, marine exploration, metal structures, power transmission, shipbuilding, etc.), agriculture (such as sprinkler irrigation, heating rooms), construction (such as water and gas transportation, wire conduit, scaffolding, houses, etc.), bridges, transportation, and other fields in recent years. Due to its beautiful appearance and good corrosion resistance, hot-dip galvanized products are becoming increasingly widely used.

　　喷涂电缆桥架喷涂桥架又可以叫喷塑桥架，粉末静电喷涂电缆桥架的原材质底板就是用镀锌板制造的，粉末经高温熔融后，固化在金属表面形成涂履层，可以有不同的颜色。涂履层能有效耐潮湿、耐化学性腐蚀。不同颜色容易进行色标管理，且提升工程美观程度；一些施工场合已明确提出必须采用静电喷涂工艺。不适宜在室外被紫外线照射容易与金属剥离。适合用在地下室等湿热环境内。不需稀料，施工对环境无污染，对人体害；涂层外观质量优异，附着力及机械强度强；喷涂施工固化时间短；涂层耐腐耐磨能力高出很多；不需底漆；施工简便，对工人技术要求低；成本低于喷漆工艺；有些施工场合已经明确提出必须使用静电喷塑工艺处理；静电喷粉喷涂过程中不会出现喷漆工艺中常见的流淌现象。

　　Spray coating cable tray, also known as spray coating cable tray, is made of galvanized sheet metal as the raw material for powder electrostatic spraying cable tray. The powder is melted at high temperature and solidified on the metal surface to form a coating layer, which can have different colors. The coating layer can effectively resist moisture and chemical corrosion. Different colors are easy to manage with color codes and enhance the aesthetic appeal of the project; Some construction sites have explicitly stated that electrostatic spraying technology must be used. Not suitable for outdoor exposure to ultraviolet radiation, which can easily peel off metal. Suitable for use in damp and hot environments such as basements. No need for thinner, construction is environmentally friendly and non-toxic to human health; The coating has excellent appearance quality, strong adhesion and mechanical strength; Short curing time for spray coating construction; The coating has much higher corrosion and wear resistance; No need for primer; Easy construction with low technical requirements for workers; Cost lower than spray painting process; Some construction sites have explicitly stated that electrostatic spraying technology must be used for treatment; During the process of electrostatic powder spraying, there will be no flow phenomenon commonly seen in the painting process.

　　防火桥架防火桥架适用于10KV以下电力电缆，以及控制电缆、照明配线等室内室外架空电缆沟、隧道的敷设。外层加防火涂料，防火桥架遇火后不会燃烧，从而阻隔火势蔓延，具有极其良好的防火阻火效果，又具有耐火、耐油、耐腐蚀、、无污染，整体安装方便，结构合理，使用寿命长，并且美观，电缆安装在电缆桥架中，环境整洁，清扫方便。防火涂料有涂层薄、耐火极限高、粘接力强的特点。防火桥架是在普通桥架表面喷涂一层防火漆，以起到防火阻燃的作用！其实桥架本身并不会着火，着火的只可能是电缆，防火漆所起到的防火阻燃原理防火桥架，表面可光面，可有磨砂感，一般运用在消防设备配电线路中，包括消防控制室、消防水泵、消防电梯、防排烟风机和火灾自动报警系统，除火灾自动报警系统外其他配电线路可采用耐火电缆，而无需采用防火桥架。防火桥架在地下车库中要求耐火时间大于1h。喷涂桥架和防火桥架的区别？喷涂桥架和防火桥架因为两者表面都是有层涂层漆，从外观上看基本分不出差别，两者的颜色均可以定制的。（以上为我厂喷涂桥架和防火桥架可供选择的部分颜色型号，可选磨砂面或光滑面，要求不同也会有所不同。因烘烤时间长短，温度高低，对色泽有影响，颜色存在一定的色差。）而他们的区别在于，虽然它们非常相似，不过喷上去的漆粉不一样，防火桥架表面上的漆面是用带有阻燃防火性的，一般是用在有消防需求的场所，具有阻燃防火性。而静电喷塑桥架是电解一层有机塑粉在表面上，目的可起到加强防腐性和美观，且防水、防油、防静电。

　　Fireproof cable tray is suitable for laying indoor and outdoor overhead cable trenches and tunnels for power cables below 10KV, as well as control cables, lighting wiring, etc. The outer layer is coated with fire-resistant paint, which prevents the fire-resistant bridge from burning in case of fire, thus blocking the spread of fire. It has extremely good fire-resistant and fire-resistant effects, as well as being fire-resistant, oil resistant, corrosion-resistant, non-toxic, and pollution-free. The overall installation is convenient, the structure is reasonable, the service life is long, and it is beautiful. The cable is installed in the cable bridge, and the environment is clean and easy to clean. Fireproof coatings have the characteristics of thin coating, high fire resistance limit, and strong adhesion. Fireproof bridge is sprayed with a layer of fireproof paint on the surface of ordinary bridge to achieve the effect of fire prevention and flame retardancy! In fact, the cable tray itself does not catch fire, and only the cables can catch fire. The principle of fire prevention and flame retardancy played by fireproof paint is that fireproof cable trays can have a smooth surface and a frosted feel. They are generally used in the distribution lines of fire equipment, including fire control rooms, fire pumps, fire elevators, smoke exhaust fans, and fire automatic alarm systems. Except for the fire automatic alarm system, other distribution lines can use fire-resistant cables instead of fireproof cable trays. Fire resistant cable trays in underground garages require a fire resistance time of more than 1 hour. What is the difference between spray painted cable trays and fire-resistant cable trays? Spray painted cable trays and fire-resistant cable trays are both coated with a layer of paint on their surfaces, and there is basically no difference in appearance. The colors of both can be customized. (The above are some color models available for our factory's spray painted bridge and fireproof bridge. We can choose frosted or smooth surface, and the price may vary depending on the requirements. Due to the length of baking time and temperature, the color may be affected, and there may be some color difference.) The difference between them is that although they are very similar, the paint powder sprayed on them is different. The paint surface on the fireproof bridge is made of flame-retardant and fireproof materials, which are generally used in places with fire protection needs and have flame-retardant and fireproof properties. The electrostatic spray coating bridge is formed by electrolyzing a layer of organic plastic powder on the surface, which can enhance corrosion resistance and aesthetics, as well as waterproof, oil resistant, and anti-static properties.

　　不锈钢桥架不锈钢桥架 ，在各类桥架优越的基础上，着重在隔热、散热、防火方面加以改进。不锈钢桥架的原料是利用不同型号材质的不锈钢板材制造而成的，表面一般不需处理，其桥架的强度、耐腐蚀度比一般桥架要高很多。不锈钢电缆桥架一般采用不锈钢（如304不锈钢、201不锈钢或316不锈钢）制成，具有较好的耐腐蚀、耐磨损、不易变形的性能，并且外观美观、寿命长。

　　Stainless steel cable tray, based on the superior performance of various types of cable trays, focuses on improving insulation, heat dissipation, and fire prevention. The raw material of stainless steel bridge is made of stainless steel plates of different types, and the surface generally does not need to be treated. The strength and corrosion resistance of the bridge are much higher than those of ordinary bridges. Stainless steel cable trays are generally made of high-quality stainless steel (such as 304 stainless steel, 201 stainless steel, or 316 stainless steel), which has good corrosion resistance, wear resistance, and is not easily deformed. They also have a beautiful appearance and a long service life.

　　铝合金桥架?铝合金桥架具有外观漂亮、结构简单、式样独特、荷载能力大、重量轻等特点。铝合金电缆桥架表面阳极氧化后，它不但抗腐蚀、还有抗电 磁干扰，尤其是抗屏蔽干扰，这是钢制桥架不可替代的。广泛应用于室内、室外的电缆、线路的敷设及维护。铝合金桥架可以方便快捷地进行拼装、安装和拆卸。此外，铝合金桥架还具备良好的隔热性能，从而提高了电缆传输效率和性，是一种、、、耐用的电缆敷设方案。

　　Aluminum alloy cable tray has the characteristics of beautiful appearance, simple structure, unique style, high load capacity, and light weight. After anodizing on the surface of aluminum alloy cable trays, they are not only corrosion-resistant but also resistant to electromagnetic interference, especially shielding interference, which cannot be replaced by steel cable trays. Widely used for laying and maintaining cables and lines indoors and outdoors. Aluminum alloy cable trays can be easily and quickly assembled, installed, and disassembled. In addition, aluminum alloy cable trays also have good thermal insulation performance, thereby improving cable transmission efficiency and safety. It is an efficient, environmentally friendly, safe, and durable cable laying solution.

　　热浸锌桥架热浸镀锌是延缓钢铁材料环境腐蚀的有效手段之一，它是将表面经清洗、 活化后的钢铁制品浸入600℃左右高温融化的锌液中，使钢构件表面附着锌层，锌层厚度对5mm以下薄板不得小于65μm，5mm及以上厚板不小于86μm。从而起到防腐蚀的目的。与?热浸锌其他金属防护方法相比，热浸镀锌工艺在镀层的物理屏障与电化学保护相结合的保护特性上，镀层与基体的结合强度上、镀层的致密性、耐久性、免维护性和经济性及其对制品形状与尺寸的适应性上，具有无可比拟的优势。目前热浸镀锌产品主要有钢板、钢带、钢丝、钢管等，其中热浸镀锌钢板所占比例。长期以来，热浸镀锌工艺因其低廉的施镀成本，优良的保护特性和漂亮的外观而备受人们的青睐，广泛应用于汽车、建筑、家电、化工、机械、石油、冶金、轻工、交通、电力、航空和海洋工程等领域。热浸锌桥架有什么优点呢？耐久年限长，生产工业化程度高，质量稳定。因而被大量用于受大气腐蚀较严重且不易维修的室外钢结构中。如大量输电塔、通讯塔等。近年来大量出现的轻钢结构体系中的压型钢板等。也较多采用热浸锌防腐蚀。热浸锌的首道工序是酸洗除锈，然后是清洗。这两道工序不彻底均会给防腐蚀留下隐患。所以必须处理彻底。对于钢结构设计者，应该避免设计出具有相贴合面的构件，以免贴合面的缝隙中酸洗不彻底或酸液洗不净。造成镀锌表面流黄水的现象。热浸锌是在高温下进行的。对于管形构件应该让其两端开敞。若两端封闭会造成管内空气膨胀而使封头板爆裂，从而造成事故。若一端封闭则锌液流通不畅，易在管内积存。由于热浸锌的工艺温度比较高，对回火温度较低的材料很容易使其在镀锌的过程中被退火，从而硬度降低。此外对配合件使用热浸锌还要考虑镀层的厚度对配合公差的影响。

　　Hot dip galvanizing is one of the most effective methods to delay environmental corrosion of steel materials. It involves immersing the cleaned and activated steel products in a molten zinc solution at around 600 ℃ to attach a zinc layer to the surface of the steel components. The thickness of the zinc layer should not be less than 65 μ m for thin plates below 5mm and 86 μ m for thick plates above 5mm. Thus achieving the purpose of corrosion prevention. Compared with other metal protection methods such as hot-dip galvanizing, the hot-dip galvanizing process has unparalleled advantages in the combination of physical barriers and electrochemical protection of the coating, the bonding strength between the coating and the substrate, the density, durability, maintenance free and economical properties of the coating, and its adaptability to the shape and size of the product. At present, hot-dip galvanized products mainly include steel plates, steel strips, steel wires, steel pipes, etc., among which hot-dip galvanized steel plates account for the largest proportion. For a long time, hot-dip galvanizing technology has been favored by people due to its low plating cost, excellent protective properties, and beautiful appearance. It is widely used in fields such as automobiles, construction, home appliances, chemicals, machinery, petroleum, metallurgy, light industry, transportation, electricity, aviation, and marine engineering. What are the advantages of hot-dip galvanized cable trays? Long durability, high degree of industrialization in production, and stable quality. Therefore, it is widely used in outdoor steel structures that are severely corroded by the atmosphere and difficult to maintain. Such as a large number of transmission towers, communication towers, etc. In recent years, there has been a significant increase in the use of profiled steel sheets in light steel structural systems. Hot dip galvanizing is also commonly used for corrosion prevention. The first process of hot-dip galvanizing is acid pickling and rust removal, followed by cleaning. Both of these processes are not thorough and can leave hidden dangers for corrosion prevention. So it must be dealt with thoroughly. For steel structure designers, it is advisable to avoid designing components with mating surfaces to prevent incomplete acid washing or incomplete cleaning of the gaps between the mating surfaces with acid solution. Causing the phenomenon of yellow water flowing on the galvanized surface. Hot dip galvanizing is carried out at high temperatures. For tubular components, both ends should be open. If both ends are closed, it will cause the air inside the pipe to expand and cause the head plate to burst, resulting in a safety accident. If one end is closed, the zinc liquid will not flow smoothly and is prone to accumulate inside the tube. Due to the high process temperature of hot-dip galvanizing, materials with lower tempering temperatures are easily annealed during the galvanizing process, resulting in a decrease in hardness. In addition, when using hot-dip galvanizing for mating parts, the influence of coating thickness on mating tolerances should also be considered.

　　常见的线槽拐弯处成品配件1.转角件：

　　Common finished accessories for trunking bends 1. Corner fittings:

　　转角件是线槽拐弯处常见的配件之一，通常有90度和45度两种角度可选。其中90度转角件适合直角拐弯，45度转角件适合斜角拐弯。在选择转角件时，需要注意转角件的角度与线槽拐弯处的角度相匹配。

　　Corner fittings are one of the most common accessories at the corners of cable trays, usually available in two angles: 90 degrees and 45 degrees. The 90 degree corner piece is suitable for right angle turning, and the 45 degree corner piece is suitable for oblique angle turning. When selecting corner fittings, it is important to ensure that the angle of the corner fittings matches the angle at the corner of the trunking.

　　2.T型接头：

　　2. T-joint:

　　T型接头可以连接三根线槽，通常用于分支线路的布线，在T型接头上可以安装转角件或者直接连接线槽。3.十字型接头：

　　T-joints can connect three cable trays and are usually used for wiring branch lines. Corner fittings can be installed on T-joints or directly connected to cable trays. 3. Cross shaped connector:

　　十字型接头可以连接四根线槽，通常用于较为复杂的线路布置。

　　Cross shaped connectors can connect four wire slots and are usually used for more complex circuit layouts.

　　（以上图例为部分样品展示，具体可提供相应图纸咨询客服相关配件信息）

　　(The above legend is a partial sample display. Specific drawings can be provided to consult customer service for related accessory information.)

　　如何选择合适的配件？在选择线槽拐弯处的配件时，需要考虑以下几个因素：1.角度：需要选择与线槽拐弯处角度相匹配的配件。2.尺寸：需要选择与线槽尺寸相匹配的配件。3.质量：需要选择质量好、材料耐久的配件，以保证线路长期稳定运行。

　　How to choose suitable accessories? When selecting accessories for the corner of the trunking, the following factors need to be considered: 1. Angle: It is necessary to choose accessories that match the angle of the trunking corner. 2. Size: It is necessary to choose accessories that match the size of the cable tray. 3. Quality: It is necessary to choose accessories with good quality and durable materials to ensure the long-term stable operation of the circuit.
