济南电缆桥架近年来的发展比较迅速，它的使用能够用于保护电缆的使用，使其使用效果比较美观、配置相对比较灵活，可以保证良好的使用效果，因其使用场合不同，电缆桥架存在有多种类型，其中就包括不锈钢电缆电缆桥架，它在安装时需要注意一些具体的步骤：

Jinan cable trays have developed rapidly in recent years, and their use can be used to protect cables, making them more aesthetically pleasing and flexible in configuration, ensuring good usage. Due to different usage scenarios, there are various types of cable trays, including stainless steel cable trays. It is necessary to pay attention to some specific steps during installation:

(1)在房间内选择电缆不锈钢电缆电缆桥架布线时，该电缆不需要黄麻或其他阻燃材料的外皮。

(1) When selecting a stainless steel cable tray for wiring in a room, the cable does not require a sheath of jute or other flame retardant materials.

(2)在有侵蚀或非常潮湿的场所选择电缆不锈钢电缆电缆桥架布线时，需要根据侵蚀物质的不同采取有效的防护措施，可以采用塑料电缆。

(2) When selecting stainless steel cable trays for wiring in corrosive or very humid areas, effective protective measures need to be taken based on the different corrosive substances, and plastic cables can be used.

(3)电缆不锈钢电缆架(托盘)水平安装时的地面长宽比一般小于2.50米，垂直安装时离地面1.80m以下的部分需要加入金属材料用盖板进行维护，但电气设备专用型的房间(例如高

(3) When installing stainless steel cable racks (trays) horizontally, the ground aspect ratio is generally less than 2.50 meters. When installing vertically, metal materials need to be added to the parts below 1.80 meters above the ground for maintenance with cover plates. However, for electrical equipment specific rooms (such as high

(4)济南电缆桥架中不锈钢电缆电缆桥架水平安装时，根据载荷曲线图选择跨度展开支撑点。 跨度一般为1.5~3M。 垂直铺设时，其支撑点间隔超过1m是不合适的。

(4) When installing stainless steel cable trays horizontally in Jinan cable trays, select span expansion support points based on the load curve diagram. The span is generally 1.5-3M. When laying vertically, it is not appropriate to have support points spaced more than 1m apart.

(5)两组电缆不锈钢电缆电缆桥架安装在同一长宽比平行面上时，各相邻电缆不锈钢电缆电缆桥架之间请考虑维护、维护间距。

(5) When two sets of stainless steel cable trays are installed on the same aspect ratio parallel surface, please consider maintenance and spacing between adjacent stainless steel cable trays.

(6)电缆线不锈钢电缆架上可以无间隔铺设电缆线，电缆线在不锈钢电缆架内横截面的填充率：电线电缆不得超过40%。 变频器电缆请控制在50%以下。

(6) Cable can be laid on stainless steel cable racks without gaps, and the filling rate of the cross-section of the cable in the stainless steel cable rack shall not exceed 40% for wires and cables. Please control the frequency converter cable below 50%.

(7)不同的动作电压、不同的主要用途的电缆不适合铺设在同一层的不锈钢电缆架上。 标准规定时，安装在同一层的不锈钢电缆电缆桥架上时，用挡板隔开。

(7) Cables with different operating voltages and main purposes are not suitable for laying on stainless steel cable racks on the same layer. When installed on the same layer of stainless steel cable trays, baffles should be used to separate them according to standard regulations.
