At present, there are many kinds of cable trays, but the surface treatment methods used for different types of trays are different. Do you know the common methods of surface treatment for trays? Is it not clear? Next, Xiaobian will take you to the following page to learn about it, hoping to help you.

1、热镀锌电缆桥架

1. Hot dip galvanized cable tray

制品酸洗-水洗-加助镀液-烘干-挂镀-冷却-药化-清洗-打磨热镀锌完工，是一种金属防腐方式，主要用于各行业的金属结构设施上。是将除锈后的钢件浸入500℃左右融化的锌液中，使钢构件外表附着锌层，从而起到防腐的意图，也是济南桥架中比较常用的一种外表处理方式。

Pickling - washing - adding auxiliary plating solution - drying - hanging plating - cooling - medicating - Cleaning - grinding and hot galvanizing of products is a metal anti-corrosion method, which is mainly used for metal structure facilities in various industries. It is to immerse the derusted steel parts into the molten zinc at about 500 ℃, so that the zinc layer is attached to the surface of the steel members, so as to achieve the purpose of anti-corrosion. It is also a common surface treatment method in Jinan Bridge.

2、冷镀锌电缆桥架

2. Cold galvanized cable tray

是利用电解设备将电缆桥架经过除油酸洗、后放入成分为盐的溶液中，并连接电解设备的负极，在电缆桥架的对面放置锌版，连接在电解设备的正极接通电源，利用电流从正极向负极的定向移动就会在电缆桥架上沉积一层锌，冷镀电缆桥架是先加工后镀锌。

It is to use the electrolytic equipment to wash the cable tray after removing oleic acid, put it into the solution composed of salt, and connect the negative pole of the electrolytic equipment. Place a zinc plate opposite the cable tray, connect the positive pole of the electrolytic equipment, connect the power supply, and use the directional movement of current from the positive pole to the negative pole to deposit a layer of zinc on the cable tray. The cold plated cable tray is processed first and then galvanized.

3、防火电缆桥架

3. Fireproof cable tray

防火桥架外观与喷塑桥架比较相似，不过性能不同，防火桥架主要性能是防火，有必定的防火等级，常用于有防火要求的场所，表面粗糙，表面摸起来会有粗糙斜斜的感觉，当遇到火灾后不会燃烧，并且能够阻隔火势继续延伸下去，起到必定的防火作用，防火涂层能够针对施工环境设计去选择桥架的色彩。

The appearance of fire-proof bridge is similar to that of plastic sprayed bridge, but the performance is different. The main performance of fire-proof bridge is fire prevention. It has a certain fire rating. It is often used in places with fire prevention requirements. The surface is rough, and the surface feels rough and oblique. It will not burn in case of fire, and can prevent the fire from continuing to extend, playing a certain role in fire prevention, The fireproof coating can select the color of the bridge according to the design of the construction environment.

电缆桥架

Cable tray

4、喷塑电缆桥架

4. Plastic sprayed cable tray

是将塑料粉末喷涂在济南桥架上的一种表面处理方法。

It is a surface treatment method of spraying plastic powder on Jinan Bridge.

以上就是为大家介绍的有关山东电缆桥架的详细介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度,为您提供服务http://www.sdhangfeng.com

The above is the detailed introduction of Shandong cable tray, which I hope will be helpful to you If you have any questions, please contact us We will provide you with professional service http://www.sdhangfeng.com
