防火桥架的作用是什么？

What is the function of fire resistant cable trays?

　　防火桥架是在普通桥架表面喷涂一层防火漆，以起到防火阻燃的作用！其实桥架本身并不会着火，着火的只可能是电缆，防火漆所起到的防火阻燃原理

Fireproof cable tray is sprayed with a layer of fireproof paint on the surface of ordinary cable tray to play a role in fire prevention and flame retardancy! In fact, the bridge itself does not catch fire. What catches fire can only be the cables, and the fire retardant principle played by the fireproof paint

　　防火桥架的防护厚度按 / T 10216一2000《电控配电用电缆桥架》表10要求，电镀大于12μm，热镀大于65μm ,喷塑大于50μm，防火大于500μm ,可以用测厚仪测出来。

The protective thickness of the fireproof cable tray shall comply with the requirements of Table 10 of /T 10216-2000 "Cable trays for electrical control and distribution", and the electroplating shall be greater than 12 μ m. Hot plating greater than 65 μ M, spray molding greater than 50 μ m. Fire prevention greater than 500 μ M can be measured using a thickness gauge.

　　阻燃防火桥架主要参数

Main parameters of flame-retardant and fire-resistant cable tray

　　外观：深灰色

Appearance: Dark gray

　　均匀稠状流体，无结块；

Uniformly viscous fluid without clumping;

　　表面干燥时间：2小时；

Surface drying time: 2 hours;

　　粘结强度：0.78Mpa；

Bond strength: 0.78Mpa;

　　抗震性：挠曲L/200涂层不起层、不脱落；

Seismic resistance: The deflection L/200 coating does not peel off or peel off;

　　抗弯性：挠曲L/100涂层不起层、不脱落；

Bending resistance: The coating does not peel off or peel off at a deflection of L/100;

　　耐火性：在自来水浸泡沫24小时以上，涂层无变化；

Fire resistance: the coating has no change when immersed in tap water for more than 24 hours in foam;

　　耐酸性：在3%HCL中浸泡沫24小时以上，涂层无变化；

Acid resistance: immerse foam in 3% HCL for more than 24 hours, and the coating has no change;

　　耐碱性：在3%Ca(OH)2中浸泡沫24小时以上，涂层无变化；

Alkali resistance: when immersed in foam for more than 24 hours in 3% Ca (OH) 2, the coating will not change;

　　耐盐性：在3%NaCl中浸泡沫24小时以上，涂层无变化；

Salt resistance: after immersion in 3% NaCl with foam for more than 24 hours, the coating will not change;

　　耐冻性：15次；

Frost resistance: 15 times;

　　不同耐火极限的涂层厚度参照如下

The reference thickness for coatings with different fire resistance limits is as follows

　　防火极限h：0.5、1、1.5、2、2.5

Fire limit h: 0.5, 1, 1.5, 2, 2.5

　　涂层厚度mm：0.4-0.6、0.8-1.0、1.4-1.6、1.8-2.0、2.4-2.6

Coating thickness mm: 0.4-0.6, 0.8-1.0, 1.4-1.6, 1.8-2.0, 2.4-2.6

　　无机耐火板

Inorganic refractory board

　　耐火性能 A级

Fire resistance performance A-level

　　导热系数（W/M、K）：≤0.5

Thermal conductivity coefficient (W/M, K): ≤ 0.5

　　抗拉强度（Mpa）：≥15

Tensile strength (Mpa): ≥ 15

　　抗压强度（Mpa）：≥45

Compressive strength (Mpa): ≥ 45

　　抗弯曲强度（Mpa）：≥35

Bending strength (Mpa): ≥ 35

　　抗冲击强度（Mpa）：≥2.0

Impact strength (Mpa): ≥ 2.0
