组合式电缆桥架向外的坡度不得小于百分之一

  组合式电缆桥架是一种新型桥架,是电缆桥架系列中的第二代产品。它适用各项工程、各种单位、各种电缆的敷设,它具有结构简单、配置灵活、安装方便、形式新颖等特点。
  The combined cable bridge is a new type of bridge, and it is the second generation of the cable bridge series. It is suitable for the laying of various projects, various units and various cables. It has the characteristics of simple structure, flexible configuration, convenient installation and novel form.
  组合式电缆桥架只要采用宽100mm、150mm、200mm的三种基型就可以组成您所需要尺寸的电缆桥架,它不需生产弯通、三通等配件就可以根据现场安装任意转向、变宽、分引上、引下。在任意部位、不需要打孔、焊接就可用管引出。它既可方便工程设计,又方便生产运输、更方便安装施工,是目前电缆桥架中理想的产品。
  As long as the three basic types of wide 100mm, 150mm and 200mm can be combined, the combined cable rack can form the cable bridge with the required size. It does not need to produce fittings such as bending and three links, and it can be changed, widened, divided, cited and directed according to the scene installation. In any part, do not need to punch, welding can be used to lead. It is not only convenient for engineering design, but also convenient for production and transportation, more convenient to install and construction. It is the most ideal product in cable bridge.
  槽式电缆桥架是一种全封闭型电缆桥架。它适用于敷设计算机电缆、通信电缆、热电偶电缆及其他高灵敏系统的控制电缆等。它对控制电缆的屏蔽干扰和重腐蚀中环境电缆的防护都有较好的效果。
山东电缆桥架
  The trough type cable bridge is a completely closed cable bridge. It is most suitable for laying computer cables, communication cables, thermocouple cables and other high sensitive systems. It has good effect on the shielding interference of the control cable and the protection of the environmental cable in heavy corrosion.
  当前大跨距电缆桥架一般是由拉挤玻璃钢型材组装而成,适用于电力电缆、控制电缆、照明电缆及配件等。与铁制桥架相比,具有使用寿命长(一般设计寿命为二十年)、安装方便且成本低(比重仅为碳钢的1/4,施工中无需动火,单根桥架长度可达8米,甚至更长)、切割方便、不需维护等优越性。
  At present, the large span cable bridge is usually assembled by the pultrusion FRP profile, which is suitable for power cable, control cable, lighting cable and accessories, etc. Compared with the iron bridge, has the advantages of long service life (general design life of twenty years), convenient installation and low cost (the proportion is only 1/4 carbon steel, no fire, in the construction of a bridge up to 8 meters in length, or even longer), convenient cutting and do not need to maintain the advantages of.
  桥架支撑点,如立柱、托臂或非标准支、构架的间距、安装方式、型号规格、标高,可同意在平面上列表说明,也可分段标出用不同的剖面图、单线图或大样图表示。
  Bridge support, such as a column, or non standard, frame spacing, installation methods, specifications, elevation, may agree to that list in the plane, can also be sub mark expressed in different sections, isometric or drawing.
  槽式大跨距电缆桥架由室外进入建筑物内时,桥架向外的坡度不得小于百分之一,在平行图上绘出桥架的路由,要注明桥架起点、终点、拐弯点、分支点及升降点的坐标或定位尺寸、标高,如能绘制桥架敷设轴侧图,则对材料统计将更精确。
  Slot type large span cable tray from the outside into the building, bridge the outward slope of not less than one percent, in a parallel graph drawn on the bridge route, to indicate the starting point and end point bridge, turning point, bifurcation points and lifting the coordinates of the point size, location or elevation, such as drawing laid on the shaft side of the map, the material statistics will be more accurate.
  公司始终坚持不断进行管理创新和科研创新,将以优良的品质、完善的售后服务赢得广大客户的信赖与支持,欢迎广大新老客户来我公司实地考察,洽谈合作!
  The company always insists on continuous management innovation and research innovation, and will win the trust and support of our customers with excellent quality and perfect after-sales service. Welcome new and old customers to come to our company for field visits and discuss cooperation.
